GridView风格视图

GridView是布局的一种，其外层可以不用其它布局。

android:numColumns="auto_fit" 列数自适应
android:columnWidth="90dp" 列宽度
android:verticalSpacing="10dp" 横竖间距
android:horizontalSpacing="10dp"

例：

<GridView android:id="@+id/GridView01"

  android:layout_width="fill_parent"

  android:layout_height="fill_parent"

  android:numColumns="auto_fit"

  android:columnWidth="90dp"

  android:verticalSpacing="10dp"

  android:horizontalSpacing="10dp"

  xmlns:android="http://schemas.android.com/apk/res/android"></GridView>

package com.iteedu.gridview;

import android.app.Activity;
import android.content.Context;
import android.os.Bundle;
import android.view.*;
import android.widget.*;

public class MainActivity  extends Activity  {
    @Override
    public void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);
        setContentView(R.layout.main);
        setTitle("GridViewActivity");
        GridView gridview = (GridView) findViewById(R.id.GridView01);
        gridview.setAdapter(new ImageAdapter(this));
    }

    public class ImageAdapter extends BaseAdapter {
        private Context mContext;
        public ImageAdapter(Context c) {
            mContext = c;
        }
        public int getCount() {
            return mThumbIds.length;
        }
        public Object getItem(int position) {
            return null;
        }
        public long getItemId(int position) {
            return 0;
        }
        public View getView(int position,
        		View convertView, ViewGroup parent) {
            ImageView imageView;
            if (convertView == null) {
            	// if it's not recycled, initialize some attributes
                imageView = new ImageView(mContext);
                imageView.setLayoutParams(
                		new GridView.LayoutParams(85, 85));
                imageView.setScaleType(
                		ImageView.ScaleType.CENTER_CROP);
                imageView.setPadding(8, 8, 8, 8);
            } else {
                imageView = (ImageView) convertView;
            }
            imageView.setImageResource(mThumbIds[position]);
            return imageView;
        }
        // references to our images
        private Integer[] mThumbIds = {
                R.drawable.grid_view_01, R.drawable.grid_view_02,
                R.drawable.grid_view_03, R.drawable.grid_view_04,
                R.drawable.grid_view_05, R.drawable.grid_view_06,
                R.drawable.grid_view_07, R.drawable.grid_view_08,
                R.drawable.grid_view_09, R.drawable.grid_view_10,
                R.drawable.grid_view_11, R.drawable.grid_view_12,
                R.drawable.grid_view_13, R.drawable.grid_view_14,
                R.drawable.grid_view_15, R.drawable.sample_1,
                R.drawable.sample_2, R.drawable.sample_3,
                R.drawable.sample_4, R.drawable.sample_5,
                R.drawable.sample_6, R.drawable.sample_7
        };
    }
}
